Taishan Group 90TPH CFB Boiler Installation in Jiangxi Province

Taishan Group 90TPH CFB Boiler Installation in Jiangxi Province

[ CFB Boiler ]

circulating fludized bed boiler

90TPH CFB Boiler is another popular coal CFB boiler model in China besides 75TPH CFB Boiler. CFB boiler is suitable for burning coal, wood chip, bagasse, straw, palm husk, rice husk and other biomass fuel. Power plant boiler manufacturer Taishan Group won a 90TPH CFB Boiler three months ago and now it is under erection. The coal CFB boiler is high-temperature and high-pressure coal boiler. The client once purchased two 35TPH Coal CFB Boilers from us, and they have been operating smoothly for five years.

Technical parameter of the 90TPH CFB Boiler

Model: DHX90-9.8-M
Capacity: 90t/h
Rated steam pressure: 9.8MPa
Rated steam temperature: 540°
Feed water temperature: 215°C
Primary air temperature:180°C
Secondary air temperature: 180°C
Primary air pressure drop: 10350Pa
Secondary air pressure drop: 8015Pa
Boiler outlet negative pressure: 2890Pa
Flue gas temperature: 150°
Boiler efficiency: 90.3%
Operation load range: 30-110% BMCR
Blowdown rate: 2%
Coal particle: 0-10mm

新闻3
 Features of the 90TPH CFB Boiler

1.Wide fuel applicability: anthracite, soft coal, low-grade coal, industrial cinder and coal gangue;
2.High combustion efficiency: the fuel burnout rate is above 98%, separation effect is good, and fly ash loss is small;
3.Large load adjustment range: minimum load can be 25-30%, and load change rate per minute is 5-10% of full load;
4.Efficient desulfurization, low nitrogen oxide emission: desulfurization rate is over 90%, and dust emission concentration is low;
5.Long service life of buried pipe: low flue gas speed, easy to replace, and service life is over 5 years;
6.Comprehensive utilization of ash and slag; low-temperature combustion has good economy and high return on investment.
7.Compact structure, small space occupation, low steel consumption, and less initial investment.

Andy Zhao

Senior Sales Manager
30+ boiler projects experience, focus on high-end customization, non-standard & special fuel boiler sales. Representative projects include waste heat boilers for Russian EVRAZ Steel, Coal CFB Boiler for Indonesia QMB New Energy Materials, HP drum & LP drum For Italian Nooter/Erisken, MP drum for Korean Hyundai Steel, LP drum for Korean POSCO Steel, 2 sets Air Cooling Coil for Finland Metso. Boiler Sales in Africa, Central Asia, Taiwan, etc.

Taishan Group 90TPH CFB Boiler Installation in Jiangxi Province Read More »

Taishan Group Wins Three Prestigious Awards in China’s Industrial Boiler Industry and Attends Industry Innovation Forum

Taishan Group Wins Three Prestigious Awards in China’s Industrial Boiler Industry and Attends Industry Innovation Forum

[ Awards ]

"Top Ten Enterprises""Advanced Export Enterprise for Foreign Exchange Earnings""Star Enterprise in New Product Development"

On December 4, 2024, the second session of the 8th General Assembly of the Industrial Boiler Branch of the China Electrical Equipment Industry Association was successfully held in Shanghai. The meeting reviewed the 2024 work report and released the “2023 Industrial Boiler Industry Technical and Economic Statistical Results” along with the “Top Ten Enterprises in Specific Categories.” Based on the 2023 industry results, Taishan Group was honored with three prestigious awards:

  • “Top Ten Enterprises”
  • “Advanced Export Enterprise for Foreign Exchange Earnings”
  • “Star Enterprise in New Product Development”

These awards reaffirm Taishan Group’s leadership position in the industrial boiler sector, showcasing the company’s excellence in innovation, market expansion, and technical advancements.

Green, Low-Carbon Development & Innovative Transformation in the Industry

During the conference, Taishan Group representatives also participated in the “2024 Industrial Boiler Industry Digital, Smart, and Low-Carbon Innovation and Transformation Technical Exchange Conference and 2024 China Industrial Boiler Industry Development Summit Forum.” At the forum, experts from across the country discussed strategies for the green, low-carbon development of the industrial boiler sector under current policies, focusing on technology and product innovation, multi-energy integration, and low-carbon sharing. These discussions provided valuable insights for optimizing and upgrading the industry.

Looking ahead, Taishan Group remains committed to its mission of “Building the Taishan Brand and Creating a Century-Long Business.” We will continue to lead the company’s development through technological innovation, market innovation, management innovation, and cultural innovation. Our goal is to enhance product competitiveness, capture market share, optimize management processes, and contribute to the revitalization and growth of China’s industrial boiler industry.

Norma Wang

Specializing in international marketing. Focus on the global market of industrial boilers.

Taishan Group Wins Three Prestigious Awards in China’s Industrial Boiler Industry and Attends Industry Innovation Forum Read More »

Taishan Group 12MW Biomass Power Plant Boiler

Taishan Group 12MW Biomass Power Plant Boiler

[ Power plant boiler ]

Power plant boiler refers to the steam boiler whose output is to drive the steam turbine and generator to generate electricity.

In 2016, Taishan Group obtained two sets of 12MW biomass CFB boiler in one biomass power generation company in China. The boiler capacity is 75t/h, steam pressure is 5.29Mpa and steam temperature is 485 Deg. C. Certainly, the electricity generated from the generator is 12MW.

Schedule for the power plant boiler

The whole production cycle is 5 months. The rst batch delivers steel frame, platform and other non-pressure parts in the third month. Second batch delivers pressure parts in the fourth month. And third batch delivers valve, instrument, guard plate, sundries and accessories in the fth month. Besides, the installation period was nished within four months.

案例3

Now the power plant boiler has operated for eight years, and the rated output is 75ton/h steam. Most importantly, this CFB boiler is our third-generation biomass boiler, which can burn a variety of biomass fuels, including waste wood, wood chip, sawdust, tree bark, etc. Above all, primary air and secondary air are reasonably allocated, combustion is stable, and combustion e ect is good. Above all, the thermal e ciency reaches 92%.

However, power plant boiler advanced design, reasonable structure, optimal material and automatically welded membrane wall guarantee low operation failure rate. Therefore, the overhaul is twice a year, small maintenance is once a month, which can guarantee annual operation of 7800-8000 hours.

Following the four-month installation was two-week commissioning and 48-hour trial operation. Certainly, it passed the performance acceptance and energy e ciency assessment, obtained the operation license from local government. Due to reliable and stable operation performance, the customer was satis ed.

 About Power Plant Boiler Manufacturer Taishan Group

Taishan Group is leading industrial boiler and pressure vessel designer, manufacturer and exporter dedicated to supply turn key coal red boiler and industrial boiler solutions to customers worldwide. Therefore, we are always working harder to become the leader in providing large or medium customized industrial boiler solution to meet market demands since its foundation in 1994. Our products extend as far as industrial boiler, power station boiler, pressure vessel, transformer, high voltage switch, electric wire and cable, residual heat refrigeration machine, etc. We had provided many types of e ective and states of the art coal red boilers, biomass boilers and other industrial boilers, pressure vessels , transformers and other related products to over 36 countries.

Taishan Group had been specializing in delivering one stop industrial boiler solutions to over 36 countries for over 20 years. Hence we are not only manufacturing best quality sand industrial boiler products but also providing professional design and installation service. Above all, OEM and ODM are also available.

Wade Zhang

CEO of Taishan Group Taian Boao International Trade Co., Ltd. 30 years experience in Global industrial boiler market,  Over 300 boiler projects experience, including 21+ EPC projects. Projects span 30+ countries & regions, involving industries such as nuclear power, energy & electricity, municipal heating, mining, textiles, tires etc.

Taishan Group 12MW Biomass Power Plant Boiler Read More »

Bangladeshi Client Explores Biomass Power Plant Boiler Solutions at Taishan Group

Bangladeshi Client Explores Biomass Power Plant Boiler Solutions at Taishan Group

[ Biomass Boiler ]

Recently, Taishan Group hosted a visit from a Bangladeshi client who is planning to establish a 10MWe power plant. During the visit, the client expressed strong interest in purchasing a 45-ton, 3.82MPa, 450°C biomass power plant boiler, with wood chips and bark as the primary fuel source.

Comprehensive Factory Tour and Collaboration Discussions

To help the client better understand the complete power plant system, Taishan Group arranged visits to turbine and generator factories in Guangzhou and Hangzhou. These factories demonstrated how steam produced by the power plant boiler is converted into electricity through turbines and generators. This end-to-end insight enabled the client to grasp the seamless integration of boiler, turbine, and generator technologies.

Key Features of the Proposed Boiler

The 45-ton power plant boiler under consideration is specifically designed to handle biomass fuels like wood chips and bark. It offers:

  • High Efficiency: Ensuring optimal combustion and energy output.
  • Environmental Benefits: Utilizing renewable biomass fuel to reduce carbon emissions.
  • Reliability: Withstanding high-pressure and high-temperature conditions for stable operation.

A Step Toward Sustainable Energy Solutions

Taishan Group’s advanced solutions in power plant boilers align with the client’s goal of achieving efficient and eco-friendly energy production. The company is committed to providing tailored solutions and professional support to meet the unique requirements of the project.

This visit underscores Taishan Group’s expertise in biomass and power plant boiler technologies and strengthens its presence in the Bangladeshi market.

Norma Wang

Taishan Group website editor, specializing in international marketing. Focus on the global market of industrial boilers.

Bangladeshi Client Explores Biomass Power Plant Boiler Solutions at Taishan Group Read More »

JDE Coffee Visits Taishan Group to Explore Biomass Boiler Solutions

JDE Coffee Visits Taishan Group to Explore Biomass Boiler Solutions

[ Biomass Boiler ]

Taishan Group recently had the honor of hosting a visit from JDE Coffee, the world’s largest single-site instant coffee factory. As part of their sustainability strategy, JDE Coffee is considering installing a 15-ton biomass boiler fueled by coffee grounds. Currently, JDE Coffee is highly satisfied with Taishan Group’s biomass boiler solution and has expressed its intention for further cooperation.

Exploring Sustainable Energy Solutions

During the visit, JDE Coffee representatives toured Taishan Group’s production workshop and visited a biomass boiler application site, where they observed firsthand the high efficiency of our biomass boilers. They learned how coffee grounds and other organic waste can be converted into clean, renewable energy, helping businesses reduce their carbon footprint and decrease reliance on traditional fuels.

Advantages of Biomass Boilers

Biomass boilers are particularly suitable for companies like JDE Coffee that are looking for environmentally friendly energy solutions, offering the following key benefits:

  • Sustainability: Biomass boilers use renewable resources such as coffee grounds, agricultural waste, and wood chips, providing a sustainable energy solution.
  • Reduced Carbon Footprint: By utilizing organic waste as fuel, biomass boilers significantly lower greenhouse gas emissions, helping businesses achieve green development.
  • Cost-Effectiveness: Using locally available organic materials as fuel helps reduce operational costs, making biomass boilers a highly efficient and economical energy option.
  • Versatility: Biomass boilers can be customized to handle different types of fuel, making them adaptable to various industries and energy needs.

Taishan Group’s Expertise in Biomass Energy Solutions

Taishan Group has extensive experience in providing high-quality biomass boilers that meet the specific needs of various industries. The 15-ton biomass boiler we are offering to JDE Coffee will allow them to utilize coffee grounds as a valuable energy resource, promoting a circular economy and aligning with JDE Coffee’s sustainability goals.

Moving Toward a Greener Future

This visit marks another significant step for Taishan Group in promoting clean energy solutions worldwide. We are confident about the potential for future collaboration and look forward to providing more companies with efficient and environmentally friendly boiler solutions.

Andy Zhao

Senior Sales Manager
30+ boiler projects experience, focus on high-end customization, non-standard & special fuel boiler sales. Representative projects include waste heat boilers for Russian EVRAZ Steel, Coal CFB Boiler for Indonesia QMB New Energy Materials, HP drum & LP drum For Italian Nooter/Erisken, MP drum for Korean Hyundai Steel, LP drum for Korean POSCO Steel, 2 sets Air Cooling Coil for Finland Metso. Boiler Sales in Africa, Central Asia, Taiwan, etc.

JDE Coffee Visits Taishan Group to Explore Biomass Boiler Solutions Read More »

Biomass Fuel Boiler Operation and Monitoring

Biomass Fuel Boiler Operation and Monitoring

Introduction to Biomass Boilers
Biomass fuel boilers, also known as biomass heating systems, use renewable biofuel to produce heat and hot water. Biofuel, typically wood pellets, chips, or logs, offers a cost-effective alternative to electricity, oil, and gas, making these boilers ideal for year-round use. Biomass fuel provides economic, environmental, and social benefits, including cost savings, fossil fuel conservation, and reduced CO₂ and NOx emissions.

Types of Biomass Fuel
Common biomass fuels include wood logs, chips, and pellets, along with agricultural waste, animal byproducts, and household waste. While wood pellets and chips can be fed automatically into the furnace, logs require manual loading. Biomass is recognized for being environmentally friendly, releasing minimal pollution during combustion.

技术3

Key Operational Procedures

1.Boiler Operation Adjustment

  • Ensure the evaporation rate aligns with the rated value, meeting steam turbine requirements.
  • Monitor and maintain stable steam pressure, temperature, and water levels to ensure safety.
  • Optimize combustion for improved efficiency and fuel savings.

2.Water Level Control
Washing the Water Gauge

  • Open the blowdown valve to flush the steam pipe, water pipe, and glass tube.
  • Close the water-side valve, and wash the steam pipe and gauge glass.
  • Alternate between steam and water-side valves, ensuring each section is thoroughly cleaned.
  • After washing, confirm that the water level rises quickly and fluctuates. If the rise is slow, repeat the process. Operators must wear protective gloves and avoid facing the gauge directly during washing.

Water Level Adjustment

  • Keep the water level at the center line of the gauge, with acceptable fluctuations within ±30mm.
  • The water supply rate should remain steady to prevent overfilling. Water levels beyond ±50mm are considered out of limits and require immediate adjustment.
  • Regularly monitor the gauge, performing daily cleaning and calibration to ensure accuracy.

3.Steam Pressure and Temperature Management

  • Rated steam pressure: 4.1 MPa, with a fluctuation range of ±0.05 MPa. Any deviation beyond these limits requires immediate action and communication with the shift supervisor.
  • Normal steam temperature: 385°C, with an acceptable fluctuation range of ±5–10°C.
  • Adjust combustion intensity and desuperheating water flow gradually to stabilize steam parameters. Sudden adjustments can disrupt operations.

4.Combustion Adjustment

  • Regulate fuel input and air volume based on load changes to maintain stable steam production.
  • Distribute fuel evenly across the grate to prevent uneven combustion and reduce the risk of coking. Ensure the fire spreads uniformly across the furnace bed.
  • Keep the combustion chamber flame golden-yellow, with oxygen levels between 4–6%, and maintain a negative pressure of 10–20 Pa.
微信图片_20240928095131


5.Boiler Blowdown Process

Types of Blowdown

  • Continuous Blowdown: Removes water with high salt content from the boiler to prevent scaling.
  • Intermittent Blowdown: Removes sediment from the water wall headers.

Blowdown Procedure

  • Check the discharge valve before initiating blowdown, and raise the water level slightly above normal.
  • Open the primary valve first, followed by the secondary valve. Once blowdown is complete, close the secondary valve, then the primary valve, following a gradual sequence to avoid water hammer.
  • If pipe vibration occurs, pause blowdown until the issue is resolved. Avoid blowdown when the water level is below normal or when personnel are working near the system.

6.Rotating Machinery Maintenance

  • Check for abnormal vibrations, noise, or misalignment. Ensure all protective covers are in place, and anchor screws are tight.
  • Lubricate bearings regularly, ensuring oil levels are adequate. Refuel oil levelers once per shift.
  • Keep bearing temperatures below 80°C, and verify that cooling water is flowing smoothly.
  • Inspect transmission belts to prevent slippage or detachment during operation.

7. Operating and Maintenance of Slag Conveyor

Ensure the motor temperature stays below 80°C, and cooling water flow is stable. Check that the belt is free of red residue, and avoid reverse operation. Maintain proper oil levels by refilling when needed.

8. Maintenance of Slag Belt Conveyor

Make sure rollers are aligned and rotate smoothly. Lubricate the grate governor box and rotating parts as required. Keep the belt clear of residue and monitor the temperature of motors, bearings, and other components. Ensure the transmission belt remains in good condition without misalignment or wear.

9. Operating and Maintenance of Biomass Fuel Boiler

Regularly inspect all key components, including pressurized parts, valves, explosion-proof doors, and structural elements. Address any issues promptly. Follow the maintenance schedule for inspections and testing, log readings accurately, and ensure the operation area remains clean for safe performance.

Wade Zhang

CEO of Taishan Group Taian Boao International Trade Co., Ltd. 30 years experience in Global industrial boiler market,  Over 300 boiler projects experience, including 21+ EPC projects. Projects span 30+ countries & regions, involving industries such as nuclear power, energy & electricity, municipal heating, mining, textiles, tires etc.

Biomass Fuel Boiler Operation and Monitoring Read More »

Taishan Group Successfully Delivers Heating Boilers for Mongolia Oil Pipeline Project

Taishan Group Successfully Delivers Heating Boilers for Mongolia Oil Pipeline Project

Recently, Taishan Group proudly completed the delivery of 16 high-efficiency single-drum horizontal chain grate (DZL) 2.8-1.0/95/75-H boilers for Mongolia’s oil pipeline heating project. This project, a significant collaboration with Mongolia Refining LLC and NORINCO International as the EPC contractor, strengthens our presence in the Mongolian energy market and sets the stage for future growth.

Project Background and Partnership

This landmark project involves Mongolia Refining LLC as the project owner, with NORINCO International as the general contractor. The project scope includes not only 16 single-drum horizontal chain grate (DZL) 2.8-1.0/95/75-H boilers but also auxiliary equipment, coal feeding systems, and environmental systems. These systems will be distributed across five heating stations, providing vital support to Mongolia’s crude oil pipeline transport.

Winning the Bid Through Collaboration and Expertise

During the bidding phase, Taishan Group’s tender office worked closely with departments like design, finance, and supply to develop a competitive proposal tailored to the client’s needs. Our team conducted meticulous cost analyses, reviewed project requirements, and submitted high-quality bid documents that ultimately secured the contract amidst strong competition. This success highlights our commitment to excellence in both project planning and customer service.

Project Execution and Quality Control

Throughout the project execution phase, Taishan Group maintained strict standards for quality control and client responsiveness. The design team actively engaged in technical exchanges with the project design institute, ensuring the equipment met all technical specifications. Additionally, our production and quality control teams worked diligently to meet third-party inspection requirements, enabling smooth and timely delivery of all components. This collaborative effort not only met the client’s expectations but also laid a strong foundation for future projects.

Establishing a Strong Reputation in Mongolia

This successful project delivery is a significant achievement for Taishan Group and reinforces our reputation in Mongolia. Following our previous heating project in Mongolia’s capital, this project represents another milestone, solidifying our position as a trusted provider of energy solutions in the region.



蒙古16台锅炉发货照片

Technical Highlights of the Single-Drum Horizontal Chain Grate (DZL) 2.8-1.0/95/75-H Boilers

The single-drum horizontal chain grate (DZL) 2.8-1.0/95/75-H boilers provided for this project offer high-performance features tailored to the needs of heating systems in colder climates:

  • Fuel: Lignite
  • Thermal Power: 2.8MW per unit
  • Pressure: 1.0 MPa
  • Outlet Water Temperature: 95°C
  • Return Water Temperature: 75°C
  • High Thermal Efficiency: Engineered for optimal energy utilization, these boilers reduce overall fuel consumption and operational costs.
  • Eco-Friendly Design: Equipped with advanced flue gas treatment technology, these systems significantly lower pollutant emissions.
  • Intelligent Control: With smart control features, the boilers adjust operating conditions based on real-time demand, ensuring stable and efficient performance.

Future Prospects in the Mongolian Market

Taishan Group is excited about the potential for continued growth in the Mongolian market. This successful delivery has enhanced our brand image and trust with local clients, providing a strong platform for future partnerships. We remain committed to developing energy-efficient boiler systems to support Mongolia’s industrial and energy infrastructure.

Wade Zhang

CEO of Taishan Group Taian Boao International Trade Co., Ltd. 30 years experience in Global industrial boiler market,  Over 300 boiler projects experience, including 21+ EPC projects. Projects span 30+ countries & regions, involving industries such as nuclear power, energy & electricity, municipal heating, mining, textiles, tires etc.

Taishan Group Successfully Delivers Heating Boilers for Mongolia Oil Pipeline Project Read More »

11 Sets Taishan Group LPG Bullet Tank Delivered to Angola

11 Sets Taishan Group LPG Bullet Tank Delivered to Angola

[ Bullet tank ]

Bullet tank is widely used in underground LPG storage.

In October 2024, high pressure vessel manufacturer Taishan Group won a big order – 17 sets LPG bullet tanks. Single LPG bullet tank has a diameter of 8m, length of 80m and weight of 480tons. The client is Angola Sonangol, and total contract value is over 20 million USD.

Due to the huge volume, we transport the manufactured tank sections to the port in batches, and then weld and assemble them.

First batch delivery includes 11 sets bullet tanks, and rest 6 sets will be delivered at the end of the year.

新闻1

Our pressure vessel products cover petrochemical, nuclear power, offshore oil and new energy equipment fields. So far, a number of high-pressure vessel products have filled domestic gap. Our comprehensive strength ranks third in the same industry in China.

In recent years, Weihai Shidao Heavy Industry has exported more than 160 sets of large-scale vessels in over ten batches. The destination is mostly “One Belt and One Road” countries and regions, and the total export value is over 60 million USD.



We will take this successful delivery as an opportunity to actively improve our technology and equipment level, strive to expand domestic and foreign markets, and make greater contributions to China’s manufacturing in the world.

Andy Zhao

Senior Sales Manager
30+ boiler projects experience, focus on high-end customization, non-standard & special fuel boiler sales. Representative projects include waste heat boilers for Russian EVRAZ Steel, Coal CFB Boiler for Indonesia QMB New Energy Materials, HP drum & LP drum For Italian Nooter/Erisken, MP drum for Korean Hyundai Steel, LP drum for Korean POSCO Steel, 2 sets Air Cooling Coil for Finland Metso. Boiler Sales in Africa, Central Asia, Taiwan, etc.

11 Sets Taishan Group LPG Bullet Tank Delivered to Angola Read More »

Sustainable Energy Solutions Using Wood Waste

Sustainable Energy Solutions Using Wood Waste

Our Mission: Promoting the Use of Renewable Energy

As a leading manufacturer of industrial boilers and power station boilers, we are committed to providing our customers with efficient and sustainable energy solutions. Recently, we welcomed two clients from Brazil who own multiple plantations. They plan to utilize wood waste from their production to build their own power plant, supplying clean electricity to the government. This collaboration not only highlights our expertise in biomass fuel but also demonstrates our commitment to sustainable development.



Touring Our Production Workshop

During their visit, we first took the clients on a tour of our production workshop, showcasing our advanced manufacturing processes and technical capabilities. Our facilities are equipped with modern equipment, ensuring that each boiler meets high standards of quality and efficiency. The clients showed great interest in our production processes, believing that this would provide solid technical support for their project.

Learning About Our Power Plant

Next, we guided the clients to our thermal power plant in Jinan. This power plant has successfully operated for nearly ten years, utilizing mixed biomass fuels (including wood chips, corn cobs, sawdust, and straw) to provide stable electricity supply to the local area. During the tour, the clients highly praised the efficient operation and environmental performance of the plant. They recognized that by using wood waste as fuel, not only can environmental pollution be reduced, but energy costs can also be effectively lowered, promoting the use of renewable energy.



Client Feedback and Future Cooperation

After the tour, we engaged in further discussions with the clients. They expressed strong interest in our technical strength and equipment, indicating a desire for close collaboration in future projects. The clients provided us with positive feedback, stating that our experience and technology in biomass utilization would offer invaluable support for their power plant construction.

Conclusion

As the global demand for renewable energy continues to grow, we are dedicated to providing innovative and sustainable solutions for our clients. We look forward to collaborating with more clients to promote the adoption and development of clean energy. If you are interested in our products and services, please feel free to contact us.

Norma Wang

Taishan Group website editor, specializing in international marketing. Focus on the global market of industrial boilers.

Sustainable Energy Solutions Using Wood Waste Read More »

10TPH Biomass Briquette Boiler to Morocco

10TPH Biomass Briquette Boiler to Morocco

Biomass Briquette Boiler is a kind of biomass boiler burning biomass particles forming fuel. Biomass briquette fuel features the following characteristics:

(1) High volatile matter and low fixed carbon, easy to ignite and burn.

(2) High hydrogen and oxygen content, conducive to combustion.

(3) Low ash content for woody biomass fuel, only about 2%.

(4) Low sulfur content, beneficial to environmental protection.

(5) Dense and regular shaped briquette fuel convenient for storage and short distance transportation.

(6) Improved energy density beneficial to automatic use.

(7) Standardized fuel lay foundation for biomass briquette boiler design standardization.

Biomass Briquette Boiler Design Analysis

Biomass briquette fuel is rod-shaped, block-shaped or granular fuel formed by extrusion, whose density is much greater than before.

The effusion rate of volatile matter and heat transfer rate are greatly reduced. The combustion includes: precipitation of water, precipitation and combustion of volatiles, and combustion of fixed carbon. In order to improve the combustion and boiler efficiency, take the following measures in the biomass briquette boiler design:

(1) The reciprocating grate with an inclination angle of 6°, not only reducing the overall height but ensuring the smooth movement.

(2) The grate reduction box adopts stepless speed control, which can accurately adjust the speed according to fuel combustion condition.

(3) The feedstock adopts variable frequency screw feeder plus distributor, ensuring accurate feeding and evenly distribution of fuel on the grate.

(4) Reasonable furnace height of biomass pellet boiler ensures lower furnace volume heat release rate.

(5) Reasonable height of secondary air ensures secondary air volume and outlet speed, and strengthens the combustion of volatile matter.

(6) Secondary air pipe is on the fire barrier, prolonging flue gas residence time and promoting the settlement of fly ash.

(7) Spirally corrugated tube has a flue gas velocity of 21m/s, preventing fly ash deposition and ensuring high heat exchange efficiency.

技术1

Biomass Briquette Boiler Structure

The biomass fuel boiler is double drum, longitudinal layout, reciprocating grate steam boiler. It includes two parts: upper boiler body and lower combustion equipment.

Upper boiler body includes drum, spirally corrugated tube, upper and lower headers, and water wall tube. The inner side is furnace wall, front and rear arches, fire barrier and flue duct. The outer side is steel frame and outer cover, and the middle is aluminum silicate insulation material.

Lower combustion equipment is 6° reciprocating grate, considering pushing and moving of fuel on grate and overall height limit.

The secondary air volume accounts for 25% of total air volume, and air speed is about 50m/s. The volatile matter of biomass briquette fuel is up to 70%. The design of secondary air is particularly important for ensuring the combustion of volatile matter and efficiency of boiler.

Andy Zhao

Senior Sales Manager
30+ boiler projects experience, focus on high-end customization, non-standard & special fuel boiler sales. Representative projects include waste heat boilers for Russian EVRAZ Steel, Coal CFB Boiler for Indonesia QMB New Energy Materials, HP drum & LP drum For Italian Nooter/Erisken, MP drum for Korean Hyundai Steel, LP drum for Korean POSCO Steel, 2 sets Air Cooling Coil for Finland Metso. Boiler Sales in Africa, Central Asia, Taiwan, etc.

10TPH Biomass Briquette Boiler to Morocco Read More »

Scroll to Top

Get Quick Support

Close
Taishan Group
Close
Make an appointment with us to meet at exhibition
Close
Quick Contact
